GENERAL
Print Method:Thermal transfer, direct thermalPrinthead:Flat headUser Interface:3x LED, 2x keyDimensions (W x D x H):200 x 267 x 198.3 mmWeight:2.9 kgMemory:128 MB (FROM), 128 MB (SRAM)Operating Temperature/Humidity:5°-40°C (41°-104°F) / 25-85% non-condensing relative humidity (RH)Storage Temperature/Humidity:-40°-60°C (-40°-140°F) / 10-90% non-condensing relative humidity (RH)Power Supply :AC 100-240 V, 50/60 Hz
PRINT
Sensor:Reflective, transmissiveResolution:GS02: 203 dpi, TS02 300 dpiMax. Print Speed:GS02: 7 ips (177.8 mm/s), TS02: 5 ips (127 mm/s)Max. Print Width:GS02: 108 mm, TS02: 105.7 mmPrint length:Batch: 6-997.9 mm, Cut: 20.4-997.9 mm*, Peel-off: 21.4-148.4 mm*Barcodes:UPC/EAN/JAN, Code 39, Code 93, Code 128, EAN 128, NW7, MSI, Interleaved 2 of 5, Industrial 2 of 5, Matrix 2 of 5, POSTNET, RM4SCC, KIX Code, Customer Barcode, GS1 DataBar, USPS Intelligent Mail Barcode2D Codes:Data Matrix, PDF 417, MaxiCode, QR Code, Micro PDF 417, Micro QR, GS1 Data Matrix, GS1 QR Code, Aztec CodeFonts:Bitmap font, outline font, price font, optional TTF, writable characters
RIBBON
Ribbon width:40 - 110 mmRibbon Core Size:25.4 mm (1"), 12.7 mm (0.5")Max Ribbon Length:300 mMax ribbon roll diameter:65 mm
MEDIA
Alignment:CentredBacking Paper Width :25.4-118 mmLabel Thickness:0.06-0.19 mmInner Media Core Diameter:Standard: 25.4, 38.1, 42 mm, Optional: 76.2 mmOuter Media Roll Diameter :Standard: Max. 127.0 mm, Optional: Max. 214 mmMedia Format:Roll, fanfold
SOFTWARE & CONNECTIVITY
Emulation:ZPL II, DPL, SBPL, EPL2, IPLPrinter Drivers:Windows 11/10, Windows Server 2019/2016/2012 R2/2012, SAP, Linux, macOSSDK:iOS, Android, .NETInterface:USB 2.0, USB Host, Ethernet 10/100 Base T (IPv4 & IPv6), Bluetooth V5.2 BR/EDR with MFi certified*/**, serial port*Language mode :TPCL, Basic Command Interpreter (BCI)Label Software :BarTender UltraLite, NiceLabel FreeIoT Device Management:SOTI Connect
